Hall Square ware Driver, Closed loop control/Speed Control

Wide speed range, 200rpm ~ 20000rpm

Input Voltage: DC 20V ~ 60V

Sofr start & stop fuction

• Rated current 20A 、Max. current 40A

External potentiometer

External Voltage and external PWM Signal speed control

• Protection function of Over voltage, Low voltage, Over current, Over hear, Error of hall sensor
